Receipt & label printer with fashion design Thermal Transfer/ Direct Thermal

Short Description:

Mode: SYLBP-T451B





Product Detail

Product Tags

Detail

Resolution203 DPI
Print methodThermal Transfer / Direct Thermal
Print speed127 mm (5")/s Max.
Max.print width104 mm (4.09")
Max.print length1778 mm (70")

Description

Media
Media typeContinuous, gap, black mark, fan-fold and punched hole
Media width25.4~118mm (1.0,,~4.6")
Media thickness0.06-0.254 mm (2.36~10mil)
Media core diameter25.4~76.2mm(1〃~3〃)
Label length10~1778 mm(0.39" ~70")
Label roll capacity127 mm (5") OD (External Diameter)
Ribbon capacityMax.300m
Ribbon width110 mm
Performance Features
Processor32-bitCPU
Memory8MB Flash Memory/ 8MB SDRAM/ Flash memory can be expanded Max.4GB
InterfaceStardard version: USB Optional:Serial/Lan/WIFI/Bluetooth/TF card
Sensors① Gap sensor ② Cover opening sensor ③ Black mark sensor ④ Ribbon sensor
Internal fonts8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software.
1D barcodeCode 39, Code 93, Code 128UCC, Code 128, subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8.EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 11
2D barcodePDF-417, Maxicode, DataMatrix, QR code, Aztec
Rotation0。、90。、180。、270°
EmulationTSPL、EPL、ZPL、DPL
Physical Features
Dimension282 mm (D) x 232 mm (W)x171 mm (H)
Weight2.56 kg
Reliability
Print head life30 km
Software
Driver

SDK

Windows / Linux / Mac Windows / iOS / Android
Power supply
Input OutputAC110-240V,1.8AI 50-60Hz

DC 24V, 2.5A, 60W


Options
Factory OptionsWiFi module

RS-252C (2400-115200 bps) communication interface;

Lon

Serial

Dealer OptionsExternal paper roll holder and 1 "paper roll

Extension board for external paper roll holder

Cutter

Peeling machine

Environmental Conditions
Operation5 ~ 40°C(41~104°F), Humidity: 25 ~ 85% non-condensing
Storage environment-40 ~ 60°C(-40~140°F), Humidity:10 ~ 90% non-condensing

Applications

Applied to many occasions and scenarios. Such as schools, homes, office and more.

Packing and Delivery

Packaging Detail:

12 pcs/carton

Delivery Detail: within 20days after order confirmed.

Shipping

We generally ship goods worldwide by sea. The products will be in a shipping container when arriving at the port. You are responsible for picking up your shipment and Customs clearance on your side.

Kindly Note

If you need large quatity,please feel free to contact us.We will provide you a competition price and high quality goods.We are professional team for printer comsumable Sincerely hope we can help you.Welcome.
