Receipt & label printer with fashion design Thermal Transfer/ Direct Thermal
Detail
| Resolution | 203 DPI |
| Print method | Thermal Transfer / Direct Thermal |
| Print speed | 127 mm (5")/s Max. |
| Max.print width | 104 mm (4.09") |
| Max.print length | 1778 mm (70") |
Description
| Media | |
| Media type | Continuous, gap, black mark, fan-fold and punched hole |
| Media width | 25.4~118mm (1.0,,~4.6") |
| Media thickness | 0.06-0.254 mm (2.36~10mil) |
| Media core diameter | 25.4~76.2mm(1〃~3〃) |
| Label length | 10~1778 mm(0.39" ~70") |
| Label roll capacity | 127 mm (5") OD (External Diameter) |
| Ribbon capacity | Max.300m |
| Ribbon width | 110 mm |
| Performance Features | |
| Processor | 32-bitCPU |
| Memory | 8MB Flash Memory/ 8MB SDRAM/ Flash memory can be expanded Max.4GB |
| Interface | Stardard version: USB Optional:Serial/Lan/WIFI/Bluetooth/TF card |
| Sensors | ① Gap sensor ② Cover opening sensor ③ Black mark sensor ④ Ribbon sensor |
| Internal fonts | 8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software. | |
| 1D barcode | Code 39, Code 93, Code 128UCC, Code 128, subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8.EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 11 | |
| 2D barcode | PDF-417, Maxicode, DataMatrix, QR code, Aztec | |
| Rotation | 0。、90。、180。、270° | |
| Emulation | TSPL、EPL、ZPL、DPL | |
| Physical Features | ||
| Dimension | 282 mm (D) x 232 mm (W)x171 mm (H) | |
| Weight | 2.56 kg | |
| Reliability | ||
| Print head life | 30 km | |
| Software | ||
| Driver SDK | Windows / Linux / Mac Windows / iOS / Android | |
| Power supply | ||
| Input Output | AC110-240V,1.8AI 50-60Hz DC 24V, 2.5A, 60W | |
| Options | ||
| Factory Options | WiFi module RS-252C (2400-115200 bps) communication interface; | Lon Serial |
| Dealer Options | External paper roll holder and 1 "paper roll Extension board for external paper roll holder | Cutter Peeling machine |
| Environmental Conditions | ||
| Operation | 5 ~ 40°C(41~104°F), Humidity: 25 ~ 85% non-condensing | |
| Storage environment | -40 ~ 60°C(-40~140°F), Humidity:10 ~ 90% non-condensing | |
Applications
Applied to many occasions and scenarios. Such as schools, homes, office and more.
Packing and Delivery
Packaging Detail:
12 pcs/carton
Delivery Detail: within 20days after order confirmed.
Shipping
We generally ship goods worldwide by sea. The products will be in a shipping container when arriving at the port. You are responsible for picking up your shipment and Customs clearance on your side.
Kindly Note
If you need large quatity,please feel free to contact us.We will provide you a competition price and high quality goods.We are professional team for printer comsumable Sincerely hope we can help you.Welcome.
