USB Label Barcode Printer for Retail, QR Code, Small Business

Short Description:

Model: SYLBP-430B

Product Detail

Product Tags


Model: SYLBP-430B

Resolving power: 203DPI

Printing method: Thermal printing

Maximum print speed: 152mm(6")/s

Maximum print width: 108mm(4.25")

Maximum print length: 1778mm

Label Volume Capacity: 101mm (4 ") OD

Media Type: Continuous, gap, black label, folding paper, perforated paper

Media width: 20~116mm(0.78"~4.56")

Medium thickness: 0. 06mm~ 0. 2 mm

Medium core diameter: 25.4~ 76.2 mm

Label length: 10~1778mm(0.39"~70")

Clearance/black mark height: Minimum 2mm


Offset of printout

Vertical: 1mm maximum, horizontal 1mm maximum

Casing: plastic cement

Volume size: 219.03 mm( L) x 189.62 mm( W) x 178.50 mm(H)

Weight: 1.58kg

Central Processing Unit: 32-bit efficient processor

Memory: 8M Flash memory


Communication interface: USB 2.0 ( ) .  WIFI ( ) .  TF Card ( )

Bluetooth (optional)

Input: AC110-240V

Power specifications

Output: DC24V/2.5A

User interface

Standard model power switch, paper output key, LED indicator (3 colors: red, purple, blue)

Sensor: Gap sensor black label sensor

Cover opening sensor: Built in font

Eight Bitmap Font Libraries: Windows font can be downloaded through software

Barcode support

1D bar code: Code 39, Code 93, Code 128UCC, Code 128subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13,EAN-128,UPC-A,UPC-E, EAN and UPC 2( 5) digits add-on, MSI, PLESSEY, POSTNET, China POST

2D bar code: PDF-417, Maxicode, DataMatrix, QR code

Font and barcode rotation


Printer Language:


Environmental conditions

Operating environment: 5~40 ℃ (41~104 ° F), humidity (non condensing) 25~85%

Storage environment: - 40~60 ℃ (- 40~140 ° F), humidity (non condensing) 10~90%

Security certification



① Windows volume label editing software, driver and operation manual CD; ② Quick installation guide; ③ Power adapter; ④ Power cord; ⑤ USB transmission line;

⑥ Paper reel, paper roll fixing plate x2


The printer will arrive 30 km or one year before the printer, and the rubber roller will arrive 30 km or one year before the printer, including serial port, Bluetooth and WFi

Factory selection

Optional for dealers

① External roll holder; ② Paper reel; ③ External support extension plate;



Applied to many occasions and scenarios. Such as schools, homes, office and more.

Packing and Delivery

Packaging Detail:

6 pcs/carton

MOQ: 10 cartons

Delivery Detail: within 20days after order confirmed.


We generally ship goods worldwide by sea. The products will be in a shipping container when arriving at the port. You are responsible for picking up your shipment and Customs clearance on your side.

Kindly Note

If you need large quatity,please feel free to contact us.We will provide you a competition price and high quality goods.We are professional team for printer comsumable Sincerely hope we can help you.Welcome.
