Performance Parameters
Specification:
Performance Parameters
Light Sources: 650nm laser (safe visible laser diode)
Decoded Capability: EAN-8, EAN-13, UPC-A, UPC-E, CODE39, CODE93, CODE128, EAN128, Codebar, Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, MSI, China Post Code, and other 1d barcodes
Scan Method: automatically; successively; manually
Scan Speed: ≥300 times / second
Scan Angle: Yaw 55°, Rotation 30°, Pitch 65°
Resolution: 3&4 mil (0.1mm)
Depth of Scan Field: 0-250mm (0.33mm, PCS90%)
Error Rate: less than 1/5million
Interface: USB-HID, USB-COM, RS232, PS2
Physical Parameters
Dimensions: 83*70*172mm
Weight: 205g
Housing Material: PC+ABS
Cable Length: 2m
Environmental Parameters
Operating Temperature: -20°C to 50C°
Storage Temperature: -40°C to 70°C
Relative Humidity: 5% to 95% RH (non-condensing / non-freezing)
Drop/Shock Resistance: withstand multiple times of 3m drops onto concrete
Electrical Parameters
Voltage: DC 5V±1%
Current: 85mA
Light Sources: 650nm laser (safe visible laser diode)
Decoded Capability: EAN-8, EAN-13, UPC-A, UPC-E, CODE39, CODE93, CODE128, EAN128, Codebar, Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, MSI, China Post Code, and other 1d barcodes
Scan Method: automatically; successively; manually
Scan Speed: ≥300 times / second
Scan Angle: Yaw 55°, Rotation 30°, Pitch 65°
Resolution: 3&4 mil (0.1mm)
Depth of Scan Field: 0-250mm (0.33mm, PCS90%)
Error Rate: less than 1/5million
Interface: USB-HID, USB-COM, RS232, PS2
Physical Parameters
Dimensions: 83*70*172mm
Weight: 205g
Housing Material: PC+ABS
Cable Length: 2m
Environmental Parameters
Operating Temperature: -20°C to 50C°
Storage Temperature: -40°C to 70°C
Relative Humidity: 5% to 95% RH (non-condensing / non-freezing)
Drop/Shock Resistance: withstand multiple times of 3m drops onto concrete
Electrical Parameters
Voltage: DC 5V±1%
Current: 85mA
