Android Barcode Printer Thermal Electronic Face Bill Printer

Short Description:

Model: TR046


Product Detail

Product Tags

Detail

Specification:

GeneralCertificateCE , FCC , CCC
Package WeightOne Package Weight1.81kgs / 3.99lb
Qty per Carton6
Carton Weight15.23kgs / 33.58lb
Carton Size76cm * 36cm * 52cm / 29.92inch * 14.17inch * 20.47inch
Loading Container20GP: 187 cartons * 6 pcs = 1122 pcs40HQ: 435 cartons * 6 pcs = 2610 pcs
OEM/ODM are Welcome! we can print customised artwork and logo

 Barcode Character:

Barcode1D bar code:Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13
EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST
2D bar code:PDF-417, Maxicode, DataMatrix, QR code
Font and barcode rotation0°、90°、180°、270°
Environment conditionOperation: 5 ~ 40°C, 25 ~ 85% non-condensing, Storage: -40 ~ 60°C, 10 ~ 90% non-condensing

Description

1. Printing method: thermal printing

2. Resolution: 203 DPI

3. Printing speed: 152 mm (6") / s

4. Printing width: 108 mm (4.25")

5. Printing length: 1778 mm (70")

6. Central Processing Unit: 32-bit RISC CPU

7. Memory: 8MB Flash Memory/8MB SDRAM/Micro SD flash memory card reader can expand the memory to 4GB

8. Communication interface: USB2.0 (standard) / TF Card (optional) / serial port (optional) / WIFI (optional) / Bluetooth (optional)

9. Power specification: external universal switching power supply / input: AC 100-240V, 1A, 50-60Hz / output: DC 24V, 2.5A, 60W

10. Printer language: TSPL, EPL, ZPL, DPL

11. Media types: continuous paper, gap paper, folded paper, perforated paper, black mark paper

12. Media width: 25.4-115mm (1"-4.5 ")

13. Media thickness: 0.06-0.25 mm (2.36-9.8 mil)

14. Diameter of the media core: 25.4-76.2 mm (1 "- 3 ")

15. Label length: 10 -1778 mm (0.39 "-70 ")

16. Appearance size: 219.03x189.62x178.50mm

17. Weight: 1.4kg



More information:

● High quality double-walled clamshell design

● 203 dpi and 300 dpi resolution models

● Head-up sensor

● USB 2.0 interface

● 8MB SDRAM, 4MB Flash

● 127mm(5'')/s high printing speed

Applications

Applied to many occasions and scenarios. Such as schools, homes, office and more.

Packing and Delivery

Packaging Detail:

6 pcs/carton

Delivery Detail: within 20days after order confirmed.

Shipping

We generally ship goods worldwide by sea. The products will be in a shipping container when arriving at the port. You are responsible for picking up your shipment and Customs clearance on your side.

Kindly Note

If you need large quatity,please feel free to contact us.We will provide you a competition price and high quality goods.We are professional team for printer comsumable Sincerely hope we can help you.Welcome.
